OUTLET DLD Eiger Mini 2 LED IP65 Plaster In Downlight True Colour CRI98 - Next Day Delivery

Manufacturer: DLD Architectural

£75

One tree planted
Trustpilot Rating
Free UK delivery
365 Day returns

View product details

Description

A versatile trimless twin downlight, the Eiger Mini 2 fixed double downlight combines smaller dimensions than our flagship Eiger with an IP65 waterproof rating with a high performance 7W True Colour CRI98 LED chip - displaying colour with greater richness and clarity. The twin plaster-in frame for the Eiger Mini is installed separately into the ceiling before plastering and decorating, creating a  seamless finish that blends with the surrounding architecture of the space. The LED downlights are then connected to the power supply and simply popped in and removed at will, avoiding the risk of damage to the luminaire during installation and allowing for easy maintenance access after install.

With an output of around 400 lumens per downlight and coupled with the CRI98 True Colour LED technology, the Eiger Mini 2 twin plaster-in downlight is the perfect light fitting for residential lighting schemes where a discreet size is needed. For a focused spot light, the narrow 15º beam angle is a great choice. If a wider general lighting effected is needed, the 36º beam angle is ideal. Luminaire in die-cast aluminium with steel housing. The heat sink is made from forged aluminium for optimum heat dissipation. In white or black.

Our downlights are fire rated as standard, and have lasted over 60 minutes in independent tests by Cambridge Fire Research. Dimmable with either 0-10V, TRIAC or DALI dimming drivers - see dropdowns above. Eiger Mini is available in single or twin versions, and with or without trim.

4000K colour temperature on demand - please contact for details.

Wireless dimming from your smartphone

This luminaire can also be used with the Casambi dimming units to give flexible control of all the lights in your home. Create the perfect mood for all situations wirelessly via Bluetooth 4.0 and save them as pre-set scenes on the Casambi app from your smartphone. Or control the scene at the touch of a button, either with Casambi wireless wall switches or with an off-the-shelf push dimmable on/off switch.  See the 'You May Also Need...' section below for the available options and technical information.

Emergency lighting compatible

Emergency pack available as an extra. By utilising the optional emergency pack this luminaire can be used as a back-up emergency light fitting that complies with standard building safety regulations. In the event of a power outage this high performance fitting becomes a low lux emergency light, operating at around 10% of it’s original performance with a battery life of 3 hours. Please contact us for details.

Delivery usually within 1-2 weeks

Lightbulb with brain filament icon
- Our Top Tips -

  • The KGP and EldoLED drivers that are available with Eiger Mini all fit through the small cutout hole
  • You can install them inline (a single driver per downlight) or remotely (one driver housed at an accessible point away from the light fittings)
  • Installing inline - if a fault occurs any issue is localised to the individual downlight, meaning the others will be unaffected
  • Installing remotely - you can power multiple downlights from one driver which keeps costs down, and house it in an easily accessible position. But if there are any issues, it is likely to affect multiple downlights at the same time
  • If installing remotely, let us know & we can recommend the best driver depending on how many fittings you are powering and the type of dimming you are using
Specification

IP65 - suitable for bathroom zone 1
Wattage: 2x 7.7W
Current: 2x 180mA
Beam angle: 15º | 24º | 36º
Adjustable tilt: 24º
Adjustable rotation: 355º
CRI 98

Beam Angle | Colour Temperature | LM/W | Delivered Lumens:
15d | 2700ºK | 50lm | 400lm
36d | 2700ºK | 51lm | 408lm
15d | 3000ºK | 52lm | 416lm
36d | 3000ºK | 54lm | 432lm
15d | 4000ºK |
36d | 4000ºK |

Plaster-in frame: 183mm x 110mm

Fire Rated:

60+ minute FR rating
Independently tested by Cambridge Fire Service

Emergency pack (optional)

1 x per light engine
3hr battery life
Low lux emergency light output
Fully compliant with standard building safety regulations

Maintenance & Access

  • LED fitting removable from the plaster-in housing post installation
  • Driver fits through the cut-out hole diameter
  • Driver can be housed remotely from the fitting (check maximum distance with us)
Dimensions

Product dimensions: W.136mm x D.63mm x H.87mm

Cutout dimensions: W.140mm x H.68mm

Downloads
Delivery and warranty

Delivery varies for each product, please see product description

About the manufacturer

Tailor-made for lighting designers and architects, the DLD Architectural lighting collection is sourced and manufactured by us to complement our Raw Design decorative lighting range. Our outstanding selection of LED architectural fittings and luminaires combines modern minimalist design with the finest components, and utilises the latest technology. Specialising in contemporary linear profile lighting, discreet yet powerful glare-free recessed downlights, modular track systems and high end exterior lighting solutions, the DLD Architectural collection is perfect for creating inspirational and innovative lighting schemes for domestic and commercial projects.

For more information on our products and services please call 01189 882294 or email [email protected].

Got a question? Email us or call 01189 882294
