LLD Altea Mini Outdoor IP67 LED Recessed Floor Uplight

Manufacturer: LLD Light

£115

One tree planted
Trustpilot Rating
Free UK delivery
365 Day returns

View product details

Description

With a mini diameter of just over 2.5cm, the LLD Altea Mini Outdoor IP67 LED Recessed Floor Uplight is a sleek and sophisticated minature outdoor luminaire that can take a walk-over weight up to 500kg. A fixed optic that is suitable for floor, wall or ceiling installation, the Altea has an IP67 rating that makes it suitable for lighting exterior pathways, steps and gardens.

Altea Mini utilises an energy efficient low wattage 1W LED light source with a 28° or 42° beam angle. Available in constant current or 24VDC constant voltage versions, and with a choice of 2700K, 3000K or 4000K light temperature. Constructed from an anticorodal aluminium body with weatherproof AISI 316L stainless steel trim & a tempered transparent glass / PMMA lens. Finished in anodised aluminium, steel or brushed steel. Supplied with a 500mm cable with WP System connection. The optional spring fitting should be used for installation into plasterboard or wood. The optional housing box should be used for installing Altea Mini into the ground. Other sizes available - see below.

350mA constant current driver (wired in series) or 24VDC constant voltage driver (wired parallel) required. This fitting is compatible with non dim, TRIAC dim, push dim, 1-10V dim and DALI dim drivers.

View the full LLD Light catalogue in the downloads tab.

Delivery usually within 2 weeks

Specification

IP67
1W
Class III
500mm cable with Water Proof connection system
Push, 1-10V and DALI dimmable with compatible driver (not included)
Lens diameter: Ø12mm
Beam angle: 28° | 42°
Cutout: Ø21mm
Wal-over: up to 500kg

Constant current version - wired in series
350mA driver required

24VDC constant voltage version - wired parallel

24VDC driver required

CCT | Lumens
2700°K | 105lm
3000°K | 111lm
4000°K | 125lm
5000°K
Red
Green
Blue

Optional housing box (CAE21): Ø25mm D.70mm
Optional spring (ML021): W.46mm D.21mm

Lamp type: LED 1W Lifespan 50,000hrs

Dimensions

Product dimensions: H.48mm x Diameter.26mm

Downloads
Delivery and warranty

Delivery usually within 2-3 weeks

August factory shutdown

Lead times in July and August can be affected by European manufacturer summer shutdowns. Need it in a hurry? Let us know and we'll check availability for you.

Supplied with a 2 year warranty covering manufacturing and/or design defects. The warranty does not cover:

  • damage caused by transport
  • the use of products in unsuitable environmental conditions
  • non-standard product use or stress including under/over voltage
  • damage caused by negligence or lack of maintenance
  • damage caused by the use of power supplies not provided or indicated by LLD Light
  • repair attempts or tampering performed by unauthorised staff
About the manufacturer

With a heritage in nautical lighting, it's no surprise that LLD Light have evolved to become a prominent manufacturer of contemporary architectural indoor and outdoor lighting. Passionate about continual research and innovation, LLD combine innovative Italian design with the highest quality locally sourced materials. Each LLD light fitting, electronics and all, is produced in Vicenza - a true example of Made In Italy.

Our LLD Light edit below showcases the most popular products in the range.

  Browse the full LLD 2021 catalogue
  Browse the full LLD News 2021 catalogue

For prices on any product that isn't shown below please contact us.



We're especially excited about their range of contemporary IP rated outdoor lighting - from adjustable spike spots and bollards, to wall lights and IP68 submersible underwater lights. Most are available in sleek and modern stainless steel, black or white, as well as COR-TEN stable rusted or in green to truly camouflage with the outdoor environment.
