Davide Groppi Frameless Recessed Track System Components

Designer: Omar Carraglia

Manufacturer: Davide Groppi

£0.0001

One tree planted
Trustpilot Rating
Free UK delivery
365 Day returns

View product details

Description

The Davide Groppi Dot Frameless is an adjustable semi recessed spotlight. The spot light is finished in matt black or matt white. The spotlight module requires a plasterboard track, power connector and power supply. Multiple spots can be joined on the same track with a linear connector and reinforcing bracket.

Optional accessories available including end caps and suspension kit. LED colour temperature in 2700K or 3000K. US version available, please contact us for pricing and more information. LED included.

In order to select multiple of the same part, such as LED modules or track, select that part only and Add To Basket. Add the total number of parts you wish to purchase, after which you can proceed to checkout.

Specification

IP20

220-240V / 50/60Hz

Composition: metal & polycarbonate

Finish: matt white or matt black

Compulsory Accessories:
LED Spotlight Module:
W. 115mm, Dia. 60mm
48V DC / LED 12W / 589lm
Compulsory installation system not included
Adjustable
DALI dimmable
LED module included
Optional LED module accessories not included
Available in matt white and matt black finishes
Available in 2700K and 3000K colour temperatures

Plasterboard Track:
48V DC / Max. 15A
Plasterboard track 12.5mm - 2000mm length
W. 74mm, H. 54mm
Plasterboard cut-out 2000mm x 26mm
Minimum space for mounting 100mm
Compulsory installation kit not included
Finished in matt black

Power Connector:
48V DC / Max. 15A
Length 112mm
Finished in matt black

Driver:
LED Driver / Input 220-240V / 50/60Hz / Output 48V DC / 150W / IP20

LED Driver / Input 90-305V / 50/60Hz / Output 48V DC / 320W / IP67

Power Kit Dim DALI / DALI dimmable / Input 220-240V / 50/60Hz / Output 48V DC / 150W / IP20

Power Kit Dim DALI / DALI dimmable / Input 100-240V / 50/60Hz / Output 48V DC / 320W / IP20

Optional Accessories:
End Cap:
Finished in matt black

End Cap for Power Connector:
Finished in matt black

Linear Connector With Reinforcing Bracket:
48V DC Max. 15A
Each linear connector is sold with a reinforcing bracket
Finished in matt black

Clamp

Suspension Kit:
Total maximum drop: 1000mm

Plasterboard Installation Guard:
Length: 2000mm

Cutting Tool

Dimensions
Downloads
Delivery and warranty

Delivery usually within 4-5 weeks.

August factory shutdown

Lead times in July and August can be affected by European manufacturer summer shutdowns. Need it in a hurry? Let us know and we'll check availability for you.

Supplied with a 2 year warranty - not including electronic and retrofit bulbs.

About the manufacturer

His father taught him how to make things when he was young. Together they made a pinball machine, a telegraph and a lamp - and it was this lamp that sparked Davide Groppi’s passion for lighting. Over fifty years later and the brands’ extensive contemporary lighting range is still winning awards, including the prestigious ADI Compasso D’Oro for their Sampei and Nulla pieces. Their playful and exciting designs include a portable rechargeable table lamp, a giant yet delicate architectural floor lamp that seems to defy gravity, and a plaster-in downlight with a cunning hidden light source.

The Davide Groppi edit below showcases the most popular products in the range.

 Browse the Davide Groppi Catalogue
 Browse the Davide Groppi Technical Handbook
 Browse the Davide Groppi Outdoor Catalogue
 Browse the Davide Groppi System Lighting Catalogue

For prices on any product that isn't shown below please contact us.



The brand is renowned for their sleek Italian lamps, meticulous design and cutting-edge LED technology. From humble beginnings in a small laboratory in the historical centre of Piacenza, their clever collaborations with talented lighting designers mean that, today, Davide Groppi is respected internationally as a superior quality lighting brand.
