DLD Lightflow CSP CRI90 IP66 Linear LED Tape - Next Day Delivery

DLD's CSP tape range makes use of Chip Scale Package technology, providing outstanding heat dissipation and efficiency, whilst maintaining a small size and light weight. Suitable for use in bathroom zone 1 thanks to its IP66 waterproof protection rating. With a slim width of 10.5mm (including the protective casing) Lightflow is suitable for use with most profiles. Available in 10W and 14.4W versions, with a choice of 2700K and 3000K temperatures, with 4000K and 6500K versions avaliable on request with a 4 week lead time. Supplied in a 5m roll with 3M self adhesive on the back, the tape can be cut every 50mm along the cut mark.

Suitable for use in architectural and residential projects, back-lighting signage, arch edge lighting, residential or commercial applications and even car decoration. IP20 and IP68 versions also available.

Dimmable by 0-10V, PWM, TRIAC and DALI depending on driver - not supplied.

View the Lightflow LED Tape collection

Wireless dimming from your smartphone

This Lightflow linear LED can also be used with the Casambi dimming units to give flexible control of the lighting in your home. Create the perfect mood for all situations wirelessly via Bluetooth 4.0 and save them as pre-set scenes on the Casambi app from your smartphone. Or control the scene at the touch of a button, either with Casambi wireless wall switches or with an off-the-shelf push dimmable on/off switch.  See the 'You May Also Need...' section below for the available options and technical information.


Recommended for installation with an aluminium profile, as this acts as a heat sink and prolongs the lifespan of the LED tape.

IP66
CRI: >90
R9: >40
PCB width: 8mm
Total width: 10.5mm (including protective casing)
Cut size: 50mm
Maximum length (10% voltage drop): 5m
3M adhesive tape

10W Version:
Voltage: 24V DC
Power (±10%): 10W/m
Light beads: 320pcs

14.4W Version:
Voltage: 24V DC
Power (±10%): 14.4W/m
Light beads: 480pcs

Dimmable by 0-10V, PWM, TRIAC and DALI - driver not included

Product dimensions: W.5000mm x D.10mm

• Data Sheet | CSP 10W | PDF
• Data Sheet | CSP 14.4W | PDF
• Bathroom Zones & IP Ratings Explained PDF
