Rako WK Hub Wired Network Interface

Manufacturer: Rako

£504


One tree planted
Trustpilot Rating
Free UK delivery
365 Day returns

View product details

Description

The WK Hub network interface is for Rako wired systems, with built-in cloud services interface, time and advanced programming features.

  • A powerful network interface for use with a Rako wired system.
  • A network and cloud interface and a link between Wired and Wireless systems.
  • Time based functionality as well as conditional logic and advanced system features.
  • The WK-HUB can be free standing or wall mounted, using the bracket provided.

NETWORK INTERFACE
Plugged either directly, or via a network, into a router, giving the system the following features; App Control, System Programming and 3rd Party Control system interface.

CLOUD INTERFACE
Allows the Rako system to be integrated with 3rd party cloud services via a ‘my.rakocontrols.com’ account including Amazon Alexa, Google Home, Apple Homekit and Sonos integration.

REAL-TIME CLOCK FUNCTIONALITY
Real-time functionality, allowing timed events, holiday mode, dawn/dusk settings and calendar scheduling. The location and time zone of the HUB can be set for anywhere in the world.

ADVANCED/CONDITIONAL PROGRAMMING
Mapping and Macro control allow advanced programming with conditional outputs from either a wired or wireless trigger command.

WIRED/WIRELESS NETWORK LINKING
Link between Rako’s wired and wireless networks retransmitting all commands, both wired and wireless.


For install enquiries contact us on:

    [email protected]

    01189 882294

or on our website Live Chat

Specification

Input supply: 15V DC from Rako Wired Network

Weight: 300g

Climate Range:
Temperature +2C to +40C
Humidity +5% to 95% non condensing

Communication:
Wired network: CAN
Wireless network: Coded fm radio,
433.9MHz, FSK transceiver
Connection via RJ45 (ethernet) port to LAN

Memory: 256 MB DDR3

Storage: 4 GB eMMC

Communication:
RJ45 Socket - Ethernet
RJ11 Socket - Rako wired network
Concentric jack - 12V Power (not required)
USB port (unused)

Standards:
Emissions - EN61000-6-3 : 2001
Immunity - EN61000-6-1 : 2001

Dimensions

Product dimensions: W.150mm x D.30mm x H.150mm

Downloads
Delivery and warranty

Delivery usually in 1-2 weeks

  Supplied with a 3 year 'return to base' warranty
