L-Tech DMX to PWM Decoder 4CH (OLED)

High end DMX decoder with real time OLED display. Capable of 8bit/16bit input and frame rate as high as 850FPS.

DMX decoder for low voltage circuits. With 4 output channels, this unit is ideal for controlling RGBW, RGB, CT or single colour LED Strip.

Input signal: DMX512/RDM
Input voltage: 5~24Vdc
Load current: 5A 4CH / Max. 20A
Output power: (0...25 120W) 480W
Dimming range: 0~100%
Protection: Short circuit/ Over current - Over-heat protection
Working temp.: -30°C~55°C

Product dimensions: W.175mm x D.30mm x H.44mm

• L Tech LT 820 5A Data Sheet

 Delivery

In Stock - UK Next Day Delivery

With over 20 years experience in designing LED lighting control, LTech are experts in creating technologically state-of-the-art LED drivers. Transform your home into a smart home with intelligent lighting control.
